Bronfman Amphitheater

  • CA CAC 58-1-10001
  • Subseries
  • between 1974 and 1982
  • Part of Moshe Safdie

The Bronfman Amphitheatre was designed for an outdoor performance area in the Jewish Quarter of the Old City of Jerusalem. During an excavation in 1977, the ruins of the New Holy Maria Church were unearthed. Due to pressure from the religious community, construction of the amphitheatre was indefinitely suspended.

Safdie Architects

Brown, MacVicar and Heriot

  • CA CAC 10.02
  • Fonds
  • 1896

"Architectural Drawings, 1896, 11 drawings." Plans, elevations and sections document the design for a house for William Robb on Mountain Street in Montreal.
"Dessins architecturaux, 1896, 11 dessins." Des plans, des élévations et des coupes témoignent du projet de construction d'une maison pour William Robb, rue de la Montagne à Montréal.

Brown, MacVicar and Heriot

Bruce Haken Wright

  • CA CAC 27
  • Fonds

The fonds contains drawings of two unidentified houses and 50 photographs documenting Wright's designs of houses as well as Wright's correspondence.

Wright, Bruce Haken, 1898-1971

Bruce Price Collection

  • CA CAC 9
  • Collection
  • 1888-1897

The collection consists of architectural drawings from 1888-1897 documenting three projects by Price: Windsor Station (1888-1889), James Ross House (extension, 1897), and an office building for William C. Van Horne in Vancouver, BC. These were some of Price's important commissions in Canada where he produced his most memorable work in a Romanesque Revival style, including the original wing of Chàteau Frontenac Hotel in Quebec City, QC (1882-1893), and Windsor Station for the Canadian Pacific Railway Company in Montreal, QC (1888-1889).

La collection inclut 35 dessins architecturaux créés entre 1888 et 1897. Il réunit trois projets de Price : la gare Windsor (1888-1889), la maison James Ross (rallonge, 1897) et un édifice à bureaux pour William C. Van Horne à Vancouver, Colombie britannique. Ceux sont parmi des plus importantes réalisations de Price au Canada où il a produit ses oeuvres de style néo-romanesque les plus mémorables : le bâtiment principal de l'hôtel Château Frontenac à Québec (1882-1893) et la gare Windsor pour la société Canadien Pacifique (1888-1889).

Price, Bruce, 1845-1903

Caesarea Heights

  • CA CAC 58-1-10005
  • Subseries
  • between 1973 and 1976
  • Part of Moshe Safdie

Caesarea Heights was an urban planning proposal for a site in Caesarea, a city positioned between Tel Aviv and Haifa. The proposed development consisted of 1,700 housing units overlooking the Caesarea Golf Course and the sea, including a variety of housing types constructed at different densities, designed to accommodate a broad range of family sizes and needs.

Clusters and individual units were designed to be particularly sensitive to orientation, and attempted to maximize views for all residents. Green spaces were integrated to separate major roads from residences, and to also provide a degree of privacy between clusters of housing. In general, the concept of "small communities" or clusters was emphasized, which is in keeping with the character of the Israeli lifestyle.

Safdie Architects

Caesarea Heights World Monument

The Caesarea World Monument involved building a World Study Center with the development of a master plan to restore and reconstruct the ancient city of Caesarea Maritima on the Sea. The entire project was divided into six phases, and Safdie's involvement was limited to the first two phases: the restoration of the Cardo Maximus, a 0.4 km pedestrian walkway extending from the amphitheatre to the moat of the Crusader Fortress; and the construction of the World Study Center Building, providing facilities for archaeological research and study, as well as for preservation and display of excavated material.

Safdie Architects

Callahan Residence

  • CA CAC 58-1-258
  • Subseries
  • between 1978 and 1981
  • Part of Moshe Safdie

Alston and Elivor Callahan owned a piece of property atop Red Mountain overlooking Birmingham, Alabama. The Callahans requested a house that would give them the sense of living in a control tower, similar to the one at Dulles Airport in Washington, DC, to overlook the city. Safdie's proposal comprised of a series of intersected cubes rotated at 45 degrees with the horizontal. The unique geometry with an elongated rectangular plan suited this unusual site. The design approach resulted in an extroverted yet transparent building that commands its surroundings.

Safdie Architects
